3inch 110W rms Compression Driver

Throat diameter 36(1.4) mm (in.)
Nominal impedance 8 Ω
Minimum impedance 6.7 Ω
Program power (1) 220 W
AES Power rating(2) 110 W
Sensitivity (3) 108.5 dB
Frequency range 500-19000Hz Hz
Voice coil diameter 75(3) mm (in.)
Magnet material Ferrite
Magnet dimensions (ODxIDxh) 170 mm
Coil material CCAR
Former material Kapton
Diaphragm material Titanium
Suspension material Titanium
Voice coil Inductance 0.10
Flux density 1.75 T
Recommended crossover (4) 1200 Hz
SHIPPING INFORMATION

Net weight 4.2 Kg
Multipack size (1) (W x D x H) 380x 370x 90 mm
Multipack weight 17.8 ( 4 pcs ) Kg
